HDPE hollow winding pipe machine
HDPE hollow winding pipe machine
Product Name: HDPE hollow winding pipe machine
Design purpose：
High speed and high efficiency extrusion on the basis of high quality,Low cost and high profit.
Function and characteristics：
Main machine
Adopting two steps type decompression screw, with special mixing and plasticization component, together with high torque and high temperature control accuracy make 90% of recovery material can be used in production.
Composite die
Adopting composite die, two extruders unite to provide material, high efficiency compound technology.
Absorbing the technical essence of Europe and Korea,ensure high production efficiency and lower material using on the condition of same circle rigidity.
Electrical control:
Advanced PLC computer control system, high precision temperature control
Model | Pipe diameter(mm) | Extruder | Capacity (KW) | Output (Kg/h) | ||
Model | L/C | Power (kw) | ||||
SKRG800 | 200-800 | SJ75×30 SJ55×30 | 30：1 | 45 | 120 | 400 |
SKRG1200 | 300-1200 | SJ90×30 SJ65×30 | 30：1 | 75 | 200 | 550 |
SKRG1600 | 800-1800 | SJ100×30 | 30：1 | 110 | 300 | 650 |
SKRG2400 | 1200-2400 | SJ120×30 SJ75×30 | 30：1 | 132 | 400 | 750 |
SKRG3000 | 1800-3000 | SJ150×30 | 30：1 | 200 | 600 | 900 |
|
